OnePlate OP6-11B
Items Per Box: 16
The re-designed OnePlate™ OP6-11B is a single flat embedded plate with 6"x5" surface area, offering 16GA steel attachment strength anywhere you need more support than standard polypropylene tabs.
Easy Installation & Detection
Simply insert the plate in areas without rebar and apply a short vibration to the face to ensure concrete consolidates into the OnePlate's grooves and holes. These plates hide seamlessly under sheetrock and are easily located with a magnet or stud finder with magnetic detection.
Versatile Applications
- Stair ledgers (basic loads)
- Curtain rod support
- Bridging ties for wood walls
- Cabinetry mounting
- Appliances and TV installations
Reinforcement in the legs is optional. See non-reinforced pullout test data on our engineering page for complete specifications.
Here's a video from an actual jobsite. Insert the plate in an area without rebar, touch it with a vibrator to get the concrete to flow through the holes and side vents.
